Features
◆ Synchronous zoom laser lighting system, with long lighting distance and large range, can realize monitoring in 0Lux all-black environment
◆ Day and night type low-illumination megapixel color-to-black camera, which can realize continuous monitoring day and night
◆ MCIC multi-core fusion mixed mode homogenization technology, no speckle dark ring phenomenon, high edge definition
◆ Adopt electronic and optical dual fog treatment technology to effectively eliminate the influence of haze
◆ Support camera back focus fine-tuning technology, can remotely debug the camera
◆ Multi-position intelligent recognition auto-focusing technology, which can adapt to a variety of scene changes and realize fast auto-focusing
◆ High-performance video processing chip, support H.264/H.265 video encoding
◆ Adopt high-precision stepping motor and precise worm gear drive, with large angle subdivision and high control precision
◆ Professionally designed shell, beautiful, light, strong, high temperature resistant, corrosion resistant, waterproof and acid rain resistant
Technical Data
| Monitoring distance | Night vision | 5000m |
| Day vision | 8000m-10000m |
| HD lens | Focal length | 16.7~1000mm |
| FOV | 0.45°~25° |
| HD Camera | sensor | 1/1.8''Progressive Scan CMOS |
| camera control | Automatic gain control, automatic white balance,
support manual and automatic day and night mode conversion |
| Fog penetration | Support (optional) |
| Noise reduction function | 3D Digital noise reduction |
| Encoding format | H.265/H.264/MJPEG |
| Video resolution | 1080p, Support three streams |
| Video bit rate | 32Kbps~16Mbps |
| Video frame rate | 50Hz:25fps(1920×1080),25fps (1280×720) |
| 60Hz:30fps(1920×1080),30fps (1280×720) |
| Image adjustment | Brightness, contrast, saturation, sharpness, etc. |
| Network protocol | TCP/IP/RTP/RTSP/HTTP/DNS/DDNS/DHCP/FTP/NTP/PPPOE/SMTP/UPNP |
| Illuminator | Power | 20W |
| Wave length | 810nm |
| Illuminating angle | 0.3°~30° continuous changing |
| Pan Tilt | Load | 50kg （top mounted) |
| Angle | Horizontal 360°continuous rotation |
| pitching -45°~+45° (-60°~+20° optional) |
| Speed | Horizontal 0.01°~12°/pitching 0.01°~8°/s |
| Preset bits | 255 bits, supporting lens zooming, focusing and preset bits |
| Accuracy | ±0.1° |
| Auto cruising | 2 paths, 64 preset bits each path |
| Auxiliary switch | 2 |
| Interface | Power supply interface | DC30V |
| Network interface | 1×10Base-T/100Base-TX，RJ45 |
| Environment indicators | Working temp | -25℃~+55℃ |
| Storage temp | -40℃~+65℃ |
| Protection grade | IP66 |
| Power supply | Power supply | Wide input AC90 ~ 295V to DC30V waterproof power supply |
| Power consumption | ≤160W |
| Physical features | Dimension | 795×353×558（L×W×H）mm |
| Weight | ≤55kg |
| Color | Ice grey |
| Installation | outdoor pedestal mounting |
