Features
◆ 640×512 Uncooled microbolometer infrared focal plane arrays
◆ Adopting continuous zooming thermal imaging technology, imaging clearly, can search in large area and recognize objectives in long distance
◆ Infrared detector with high temp sensitivity, with min temp resolution of 50mK
◆ Day and night 2 megapixels low illuminating color camera, realizing day and night continuous monitoring
◆ Optional auto focusing function, realizing multiple focusing mode and triggering mode
◆ Optional thermal imaging camera presetting function, remembering FOV of each preset bit, enhancing working efficiency
◆ Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain
Technical Data
| Monitor distance | Visible light | Day vision | 1000m |
| Thermal Camera | Object | Human (1.8m×0.5m) | Vehicle(2.3m×2.3m) |
| Detection distance | 2800m | 8000m |
| Recognition distance | 930m | 2000m |
| Identification distance | 460m | 1000m |
| Thermal lens | Focal length | 25～100mm, 4× optical zoom |
| FOV | 4.6°×3.7°～18.2°×14.6° |
| F value | F1.0 |
| Lens control | electric zooming, electric focusing(auto focusing optional) |
| Thermal Detector | Detector type | uncooled microbolometer focal plane array(VOx) |
| Resolution | 640×512 |
| Spectral range | 8～14μm |
| NETD | ≤50mK@F1.0,300K |
| Image processing | DDE, pseudo color |
| HD Camera | Focal length | 4.8～120mm, 25× optical zoom |
| Auto focusing | support |
| Sensor type | 1/2.8” Progressive Scan CMOS |
| Coding | H.264/MJPEG/MPEG4 |
| Video resolution | 1920×1080 |
| Video frame rate | 1～25f/s (50Hz),1～30f/s (60Hz) |
| Pan-tilt | Carrying capacity | 20kg (top load) |
| Angle | Horizontal 360°continuous rotation, pitching: -60°～+20° |
| speed | Horizontal 0.01°～12°/s, pitching 0.01°～8°/s |
| Preset | 200 |
| Cruising | 8 paths, 10 bits each path |
| Anti-lightning | 2000V |
| Interface | Power supply | AC24V |
| Network interface | 1×10Base-T/100Base-TX, RJ45 |
| Other interfaces | RS422 communication, BNC video output |
| Environment indicators | Working temperature | -25℃～+55℃ |
| Storage temperature | -40℃～+65℃ |
| Protection grade | IP66 |
